EVA – 750-HS

Benefits :

  • Industrial Air Coolers Improves indoor air quality by removing dust, fumes & odours.
  • Improves productivity in industries through 100% fresh, clean & cool air.
  • Low Capex &Opex.
  • Industrial air coolers are Cost Effective and Energy Efficient.
  • Consumes upto 80% less electricity than refrigerated air conditioning.
  • Green & Sustainable Evaporative Technology.
  • Strong protection from electric faults.

Description

PRODUCT FEATURES

  1. High static air pressure and long distance air delivery .
  2. Robust wired Remote controller .
  3. In-built single phase preventer ,short circuit and overload protection.
  4. High efficiency Honey Comb Cooling Pads with higher saturation levels.
  5. Heavy duty Submersible type water pump for continuous water supply.
  6. Industrial air coolers have Rust free Stainless steel tank of large capacity
  7. Non-clogging type water distributor to ensure uniform flow of water over pads.
  8. 100% copper wounded electric motor for durability and Aluminium casing to ensure fast heat dissipation.
  9. Industrial Air coolers manufactured with AMCA Certified Forward curved DIDW Centrifugal Fan.
  10. Easy to Operate and Maintain.
  11. Pre-dust filters to ensure dust free fresh air and longer life of pads.
  12. Float valve to ensure continuous water supply and maintain set water level.
  13. Powder Coated GP sheet strong cabinet
  14. Customisable to variable speed and to any capacity upto125000 CFM

Specifications

SPECS/MODEL EVA-750 HS
Discharge Type Side
Airflow(m³/hr) CMH 75000
Airflow(ft³/min) CFM 45000
*Area Coverage (SFT) 9000
Static Pressure (mmwg) 40
Power(kw) 18.5
Power Resource (V/Hz) 415/50
Fan Type Centrifugal Blower
Fan Speeds 3-Phase, Single Speed
Vent Size (L x W) mm 1270 X 1230
Noise(dBA) ≤ 70
Back Pad Size(L x H x W) 870 X 1730 X 100 (2 Nos.)
Side Pad Size(L x H x W) 870 X 1730 X 100 (2 Nos.)
Dimension(L x W x H) (2880 X 2880 X 2480)±100
Net Weight(KG) 600
Operation Weight (KG) 1450
Low Water Sensor
Controller Wired Remote
Pre-Dust Filter
Tank Capacity (Litre) 500
Evaporation Efficiency 85%
